First pic is from a while back just hadn't posted it in here yet. Second pic I just took recently while at home in PA. I included two edits of it cause I can't decide which I like more.
![]()
![]()
![]()
Lexus IS-F Build Thread - Wheel Pictures Page 6 - 7.13.2011
101 - 120 of 124 Posts
Joined
·
5,879 Posts
Yes those are LC818. I got them for a set of winter wheels.
Joined
·
5,879 Posts
Weekend install complete
A while back I picked up the Branew lip kit a member on ClubLexus was selling. I finally was able to have time to install it this weekend. I documented some of the install as the only way to really correctly install it was to remove the front bumper and side skirts from the car since the kit doesn't use factory mounting points except at the end of the front and rear bumper.
The install wasn't terribly difficult just more so time consuming due to having to remove the front bumper and sides. The kit also is rather hard to fit with the ISSForged exhaust because it goes into the exhaust openings on the bumper and thus makes them a little smaller. I fixed this problem a little by switching out so some different size rubber exhaust hangers in order to move the exhaust around in the opening a bit.
I am still working on fitting the rear piece in a final position as the original install they used pop rivets that were hidden but I don't really want to drill those holes in the bumper because they would not be 100% hidden when I would eventually remove the kit.
Well onto the install and pics.
New slightly smaller rubber exhaust hangers.
![]()
This spot on the rear lip mounts to the bolt right before the wheel arch in the picture below. Those bolts one on each side are technically the only thing holding the rear lip on. It does however fit tightly around the exhaust as well so it is pretty much permanently held on. Once I get a few more things figured out I will then attach it with 3m body tape as well. Hopefully till then it will stay on safely.
![]()
![]()
Rear lip on and car up on ramps and boards to give a slight increase in clearance to complete the rest of the install.
![]()
I chose all stainless steel hardware to bolt in on with. I got nylon locking nuts as to help prevent the need to ever have to retighten anything since I would have to remove it from the car first which would be a pain.
![]()
Front wheel arch remove top bolt
![]()
Remove 2 bolts and 1 clip here.
![]()
Rear wheel arch remove single bolt on side skirt
![]()
Remove clip from flap
![]()
Remove bolt from flap
![]()
Remove 7 clips on underside of sideskirt
![]()
Remove 2 screws under weather stripping one at front and one at back. The front ones were rather a pain because I could not get in a position to be able to see into it so as to line up the screw driver.
![]()
![]()
Side skirts finally off
![]()
Now on to removing the front bumper. There are 9 clips on the top panel.
![]()
Below that there are 3 bolts. 1 on each side and one in the middle.
![]()
I forgot to grab pictures but there are two plastic clips inside each wheel arch and then one screw which you have to pry the fender liner out first to access at the top corner of the bumper. Then there are 8 bolts to be removed on the bottom side of the bumper. Once are of that is out carefully pull the bumper out of the clips underneath the side and inner corner of each headlight.
You will either need someone to hold the bumper or or lay it down at an angle and quickly disconnect the fog light wires so as not to put strain on them. Also need to disconnect the harness that is for the headlight washers and parking sensors.
Lastly make sure you have something to clamp the hose from the washer fluid container or else you will end up with a mess like I did the first time. Not really sure what I thought was going to stop it from coming out all over the place.
![]()
Bumper finally off
![]()
A while back I picked up the Branew lip kit a member on ClubLexus was selling. I finally was able to have time to install it this weekend. I documented some of the install as the only way to really correctly install it was to remove the front bumper and side skirts from the car since the kit doesn't use factory mounting points except at the end of the front and rear bumper.
The install wasn't terribly difficult just more so time consuming due to having to remove the front bumper and sides. The kit also is rather hard to fit with the ISSForged exhaust because it goes into the exhaust openings on the bumper and thus makes them a little smaller. I fixed this problem a little by switching out so some different size rubber exhaust hangers in order to move the exhaust around in the opening a bit.
I am still working on fitting the rear piece in a final position as the original install they used pop rivets that were hidden but I don't really want to drill those holes in the bumper because they would not be 100% hidden when I would eventually remove the kit.
Well onto the install and pics.
New slightly smaller rubber exhaust hangers.
This spot on the rear lip mounts to the bolt right before the wheel arch in the picture below. Those bolts one on each side are technically the only thing holding the rear lip on. It does however fit tightly around the exhaust as well so it is pretty much permanently held on. Once I get a few more things figured out I will then attach it with 3m body tape as well. Hopefully till then it will stay on safely.
Rear lip on and car up on ramps and boards to give a slight increase in clearance to complete the rest of the install.
I chose all stainless steel hardware to bolt in on with. I got nylon locking nuts as to help prevent the need to ever have to retighten anything since I would have to remove it from the car first which would be a pain.
Front wheel arch remove top bolt
Remove 2 bolts and 1 clip here.
Rear wheel arch remove single bolt on side skirt
Remove clip from flap
Remove bolt from flap
Remove 7 clips on underside of sideskirt
Remove 2 screws under weather stripping one at front and one at back. The front ones were rather a pain because I could not get in a position to be able to see into it so as to line up the screw driver.
Side skirts finally off
Now on to removing the front bumper. There are 9 clips on the top panel.
Below that there are 3 bolts. 1 on each side and one in the middle.
I forgot to grab pictures but there are two plastic clips inside each wheel arch and then one screw which you have to pry the fender liner out first to access at the top corner of the bumper. Then there are 8 bolts to be removed on the bottom side of the bumper. Once are of that is out carefully pull the bumper out of the clips underneath the side and inner corner of each headlight.
You will either need someone to hold the bumper or or lay it down at an angle and quickly disconnect the fog light wires so as not to put strain on them. Also need to disconnect the harness that is for the headlight washers and parking sensors.
Lastly make sure you have something to clamp the hose from the washer fluid container or else you will end up with a mess like I did the first time. Not really sure what I thought was going to stop it from coming out all over the place.
Bumper finally off
Joined
·
5,879 Posts
So I was worried about scrapping the front lip and since it was carbon and I didn't want to damage it I did a little research and found two solutions. One using industrial Velcro and the other a 3M product used on airplane front ends and helicopter blades that seems pretty indestructible. The 3M product is extremely expensive and I was unable to figure out if you needed a special adhesive to apply it so I went with the easier solution that I could pickup at Lowes.
![]()
You don't use the hard plastic stuff but rather the softer thicker part of the Velcro.
![]()
![]()
![]()
![]()
![]()
Lip finally installed on the bumper
![]()
Couple shots of the hardware installed and at the end of the bumper you can see how the last mounting location uses the factory hardware. I chose to use the factory holes to start with to bolt the lip on to align it to the bumper before drilling the holes in the bumper to install the other bolts.
![]()
![]()
![]()
Shot before installing the side skirts.
![]()
The side skirts didn't have a factory bolt hole to use to help align so a buddy of mine came over to help me hold it in place after I lined up each end before drilling the outer holes. I forgot to take any pics of the rest of the side skirt install cause I was getting tired at this point. Also no pics of the re-install but just pretty much do the reverse of taking it apart.
Only able to get 3 shots of it today as it rained for most of the day unforunately. The sun did come out though so I could at least get these.
![]()
![]()
![]()
You don't use the hard plastic stuff but rather the softer thicker part of the Velcro.
Lip finally installed on the bumper
Couple shots of the hardware installed and at the end of the bumper you can see how the last mounting location uses the factory hardware. I chose to use the factory holes to start with to bolt the lip on to align it to the bumper before drilling the holes in the bumper to install the other bolts.
Shot before installing the side skirts.
The side skirts didn't have a factory bolt hole to use to help align so a buddy of mine came over to help me hold it in place after I lined up each end before drilling the outer holes. I forgot to take any pics of the rest of the side skirt install cause I was getting tired at this point. Also no pics of the re-install but just pretty much do the reverse of taking it apart.
Only able to get 3 shots of it today as it rained for most of the day unforunately. The sun did come out though so I could at least get these.
Joined
·
4,047 Posts
Nice install, kit looks great!
Joined
·
5,555 Posts
Joined
·
5,879 Posts
Actually you might think that but because it is hard each time you scrape it it will wear down. The soft side on the other side just compresses and still keeps you from scraping the bottom and thus doesn't really wear away at all.
Joined
·
5,879 Posts
Joined
·
4,047 Posts
What a daily :drool1:
Joined
·
5,879 Posts
Joined
·
2,459 Posts
Looks amazing
Joined
·
5,879 Posts
So well the IS-F has been upgraded. In the process of trying to get it sold now. It was time to move on to something bigger with more storage. I have 4 dogs so travel was tight in the IS-F. I wanted something that handled as well and had close to the same amount of lower. In the end it has more power and handles close to the IS-F but the F still get the nod in the handling department. Might just be the 14k coils I had put on it though. Here is the new ride.
![]()
![]()
![]()
![]()
My newest edition to the family Enzo hanging out next to the new ride parked in the garage with the TSX.
I still have the TSX but nothing has changed since the rebuild really. I have some plans but with buying a house a year ago and now a new car the modding of the TSX has been put on the back burner. It will eventually happen though again. It is still my first love.
My newest edition to the family Enzo hanging out next to the new ride parked in the garage with the TSX.
I still have the TSX but nothing has changed since the rebuild really. I have some plans but with buying a house a year ago and now a new car the modding of the TSX has been put on the back burner. It will eventually happen though again. It is still my first love.
Joined
·
2,900 Posts
Love the "roomy" caddy.
Glad to see u still have the TSX.
I've contemplated letting go of mine in lieu for a truck many times. I spend a lot of time on the road hiking, biking, at the beach, etc...with the fam so it would be sooo much more convenient....but I'm having a hard time letting go.
Glad to see u still have the TSX.
I've contemplated letting go of mine in lieu for a truck many times. I spend a lot of time on the road hiking, biking, at the beach, etc...with the fam so it would be sooo much more convenient....but I'm having a hard time letting go.
